Graphite electrode for EDM (Electrical Discharge Machining) is a process of electrical discharge machining that utilizes electrical sparks to create a mechanical effect between the electrode tool and the workpiece. Graphite material is ideal for this type of process due to its high dimensional precision and fine surface finish. The right graphite can increase productivity and finish quality. Despite the fact that there are many graphite materials and brands available, it is often difficult to decide which one will suit your requirements.
The physical and mechanical characteristics of the graphite electrode are crucial to the success of an EDM process. The grade of graphite you choose will determine how accurate your machining is, and the overall performance of the process. To choose the best graphite grade for a particular application, it is important to understand the different grades, their microstructures and the physical and chemical characteristics. It is also important to maintain, handle, and store an electrode properly. This will increase its lifespan.
The EDM creates a channel of plasma between the electrodes and the workpiece material. By melting and by vaporizing, the plasma erosion process causes damage to the workpiece material. Voltage between electrode and workpiece, as well as intensity, pulse length and interval time of current determine the amount of erosion. It is also important to consider the particle size and finish of the surface.
A material's resistance to thermal shock is directly related its machinability. Graphite retains its shape better during an electrical breakdown, as it has a coefficient of thermal growth that is lower than copper. In addition, it has a density that is five times lower than copper, making it a lighter material. ELLOR from Mersen is a superior material for electrodes due to its machinability.
Every machine shop must make a decision about the electrode they use. In order to achieve superior performance, a good EDM should have a high resistance to cracking. It is important to maintain the geometrical shape of the EDM electrode while processing. This will also allow for a greater metal removal rate, and minimize corner wear. The graphite in the electrode must also be of high melting temperature and free from impurities which can discolour or degrade its surface.
EDM is one of the most sensitive methods for machining. It requires very fine control over spark gaps. It is crucial to achieve a high-quality surface finish. An electrode's ability to maintain the spark gap properly will be determined by its grain structure. Ideal graphite should be uniform in microstructure, with smaller grains to produce a finer finish than materials of larger grain. Regular cleaning and reconditioning of graphite will prevent contaminants that can negatively affect the conductivity of electrodes.
